Thermal_Grease

SC4476 CV

Thermally Conductive Compound

● 일반적 특성


Property Unit Result
One part or Two part - One
Color - Gray
Viscosity cP 310,000
  mPa-sec 310,000
  Pa-sec 310
Specific gravity (uncured) - 3.04
Thermal Conductivity btu/hr-ft- o F 1.792
  W/m-K 3.1
Content of Low Molecular Siloxane (D4-D10) ppm 60
Dielectric Strength volts/mil 635
  kV/mm 25
Volume Resistivity ohm-cm 1.5E+00
Dielectric Constant (at 50 Hz) - 5.4
Dissipation Factor (at 50 Hz) - 0.1
