| feature | unit | Thermal Adhesive | ||||||||||||
| SE4420 | SE4422 | SE4486 | SE4485 | SE9184 | EA9189H | SE4402 | 1-4173 | 1-4174 | 3-6752 | SE4450 | TC2035 | DA-6534 | ||
| Part | one | one | one | one | one | one | one | one | one | one | one | two | One | |
| Color |
Part A Part B Mixed |
White | Gray | White | White | White | White | Gray | Gray | Gray | Gray | Gray |
White Reddish Brown |
Gray |
| Viscosity | cP (mpa.s) | 108,000 | 200,000 | 20,000 | 230,000 | Nonflow | Nonflow | 34,000 | 61,000 | 62,300 | 83,300 | 66,000 | 125,000 | 103,000 |
| Specific Gravity (Cured) | 2.26 | 2.2 | 2.59 | 2.9 | 2.2 | 1.68 | 2.16 | 2.7 | 2.71 | 2.61 | 2.73 | 4.4 | ||
| Cure Type(상온, Cure) | 상온 | 상온 | 상온 | 상온 | 상온 | 상온 | Cure | Cure | Cure | Cure | Cure | Cure | Cure | |
| Tack-Free Time at 25 ºC | min | 10 | 10 | 4 | 12 | 3 | 2 | NA | NA | NA | NA | NA | NA | |
| Working Time at 25 ºC | hour | 4 | ||||||||||||
| Cure Condition | min | 7 days | 48Hours | 120Hours | 48Hours | 72Hours | 150C @ 30 |
100C @ 90 125C @ 30 150C @ 20 |
100C @ 90 125C @ 30 150C @ 20 |
100C @ 40 | 150C @ 30 |
125C @ 30 150C @ 10 |
150C @ 120 | |
| Thermal Conductivity | w / mk | 0.92 | 0.9 | 1.6 | 2.8 | 0.84 | 0.88 | 0.92 | 1.8 | 1.78 | 1.7 | 1.92 | 3.3 | 6.8 |
| Tensile Strength | psi | 600 | 206 | 4.1MPa | 3.7MPa | 460 | 576 | - | - | - | 965 | 522 | - | |
|
Unprimed Adhesion - Lap Shear to Aluminum |
psi | 390 | 230 | 243/GL | 200/GL | - | 363 | 488 | 650 | 646 | 518 | 500 | 448 |
1.3Mpa 194 psi |
| Durometer | shore A,D | A76 | A68 | A80 | A91 | A74 | A80 | A74 | A92 | A92 | A87 | A95 |
A95 D45 |
A91 |
| Elongation | psi(%) | 77% | 130% | 45% | - | - | 60% | 40% | - | - | - | 46% | 43% | - |
| Dielectric Strength | kv/mm | 14.6 | 14.4 | 20 | 19 | 20 | 28 | 16 | 16 | 16 | 22 | 21 | - | |
| Volume Resistivity | ohm*cm | 1.00E+15 | 5.00E+15 | 2.00E+14 | 8.00E+14 | 1.50E+15 | 3.30E+15 | 1.90E+14 | 1.90E+14 | 7.10E+13 | 3.30E+15 | 5.50E+15 | 1.80E-04 | |
| UL Flammability Classification | UL94 V-1 | UV94 V-0 | UV94 V-0 | UV94 V-0 | UV94 V-0 | UV94 V-0 | UV94 V-0 | |||||||
| Shelf life | month | 10 | 9 | 9 | 7 | 9 | 6 | 6 | 6 | 6 | 6 | 6 | 4 | |
